Download Manual The BG-UHD-KVM41MV is a powerful 4×1 seamless UHD KVM switcher designed to simplify multi-computer workflows while delivering uncompromised 4K60 video performance. It allows up to four HDMI source devices to be displayed and controlled on a single monitor, supporting both full-screen switching and advanced multiview layouts with smooth, glitch-free transitions.
Combining professional-grade video switching with full USB 3.0 KVM functionality, the BG-UHD-KVM41MV enables users to control multiple computers using one keyboard, mouse, and shared USB peripherals. With flexible control options, audio de-embedding, and broad OS compatibility, it is ideal for control rooms, broadcast environments, post-production, IT workstations, and collaborative professional AV applications.
Features In-DepthThe BG-UHD-KVM41MV supports HDMI 2.0b video at resolutions up to 4K@60Hz 4:4:4 with 18Gbps bandwidth, ensuring crystal-clear image quality for detailed content and data-driven workflows. Seamless switching technology eliminates black screens or signal drops when changing inputs, making it well suited for mission-critical environments. An integrated multiview engine provides eight display layouts – including Single, PIP, PBP, Triple, and Quad – allowing multiple sources to be monitored simultaneously on a single UHD display.
As a full-featured KVM solution, the unit integrates USB 3.0 host switching with a built-in USB hub, enabling fast peripheral sharing at up to 5Gbps. Each HDMI input is paired with a corresponding USB host connection, ensuring synchronized video and USB control when switching sources. Advanced keyboard and mouse hotkeys, mouse roaming, and front-panel controls provide intuitive and efficient operation across connected systems.
Audio flexibility is equally robust, with HDMI audio pass-through up to 7.1 channels and audio de-embedding via analog RCA and optical S/PDIF outputs. Independent audio routing allows users to select and control audio separately from video, while EDID management ensures stable compatibility across a wide range of source devices and displays. Multiple control interfaces – including OSD, IR remote, RS-232, and PC software – make the BG-UHD-KVM41MV easy to integrate into both standalone and automated AV systems.
Features- Seamless HDMI Switching – Switch between four HDMI sources to one display with no signal interruption
- 4K@60Hz Support – HDMI 2.0b with 18Gbps bandwidth and full 4:4:4 color
- Advanced Multiview – Eight display modes including Single, PIP, PBP, Triple, and Qua d
- USB 3.0 KVM – Control up to four computers with one keyboard, mouse, and shared USB devices
- Advanced Audio Control – Analog and optical audio outputs with flexible source selection
- Multiple Control Options – Front panel, IR remote, OSD, hotkeys, RS-232, and PC control software
