Description
Support a mix of multiple video formats using the Videohub 10×10 12G Zero-Latency Video Router from Blackmagic Design. This advanced router provides 10 12G-SDI inputs and ten 12G-SDI outputs for routing any combination of SD, HD, UHD 4K, and DCI 4K video. The Videohub 10×10 12G centralizes all your SDI cables in one hub, allowing you to connect any video input to any output or route a single input to multiple outputs. This simplifies cabling and eliminates the need for complex routing diagrams.It can be used with multiple HyperDeck recorders for redundant mastering, route video to multiple streaming processors for broadcast platforms, or expand input capabilities of an ATEM switcher.
12G-SDI Multi-Rate Connections
Multi-rate 12G-SDI connections allow routing of up to 10 different video standards simultaneously.
Supports resolutions up to DCI 4K60.
Provides 4:2:2 8-bit or 10-bit color routing in any standard.
Supports 4:4:4 12-bit SDI up to DCI 4K30 for feature film workflows.
SDI Reclocking
Reclocking on every 12G-SDI input regenerates the signal for maximum video quality.
Reduces or eliminates signal loss and jitter, especially over long cable runs.
Front Panel Controls
Sleek front panel with intuitive controls.
Includes assignable shortcut buttons plus In, Out, Clear, and Take controls.
Features a precision machined metal spin knob with electronic clutch for accurate adjustments.
Optional Hardware Control Panels
Compatible with optional control panels for larger installations.
Works with Videohub Master Control Pro and Videohub Smart Control Pro for expanded control flexibility.
Flexible Control
Videohub Software Control (macOS and Windows compatible) provides touchscreen-based router management.
Enables quick and intuitive routing adjustments from a computer interface.
Built-In LCD
Integrated 2.2″ LCD screen lets you preview live inputs before routing.
Bottom labels allow scrolling through sources alphabetically.
Eliminates the need for an external SDI monitor.
Setup Utility and SDK
Use Videohub Setup software for initial configuration.
SDK allows integration with broadcast automation systems and custom workflows.
Multiple Language Support
Available in:
English, Chinese, Japanese, Korean
Spanish, German, French, Russian
Italian, Portuguese, Turkish, Polish, Ukrainian
