| Mechanical Specifications | |
|---|---|
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination |
0.01 Lux @(F1.2, AGC ON) 0.028 Lux @(F1.2, AGC ON) 0 Lux with IR |
| Shutter Speed | 1/5 s – 1/20,000 s |
| Lens Type | 2.8 mm |
| Lens Mount | M12 |
| Day and Night | IR Cut Filter with Auto Switch |
| Dynamic Range | Wide Dynamic Range |
| Digital Noise Reduction | 2D / 3D DNR |
| Compression | |
| Video Compression | H.265 / H.264 / MJPEG |
| Image Resolution | Up to 5MP (2560 × 1960) |
| Video Bit Rate | 265K – 8M |
| Image | |
| Frame Rate |
5MP (2592 × 1944) @ 15fps 4MP (2592 × 1520) @ 15fps 1080P (1920 × 1080) @ 15fps 720P (1280 × 720) @ 15fps 960H (1280 × 960) @ 15fps Substream @ 30fps D1 (704 × 480) / VGA (640 × 480) / QVGA (320 × 240) @ 30fps Mobilestream @ 10fps QVGA (320 × 240) @ 1–30fps |
| Image Settings | Rotate Mode, Saturation, Brightness, Contrast, Sharpness, Adjustable Browser |
| Day and Night Switch | Auto / Schedule / Triggered by Alarm In |
| Interface | |
| System Compatibility | ONVIF 2.4, RSSP |
| Interface | 1 × RJ45 10M / 100M Ethernet Interface |
| IR Distance | Flux IR up to 75 ft |
| PoE | Built-in PoE |
| Security | Flash-Prevention, Dual Stream, Heartbeat, Mirror, Password Protection, Privacy Mask, IP Address Filtering |
| Electrical | |
| Power Supply | 12 VDC ±10%, PoE (802.3af) |
| Power Consumption | Max. 5W (Max. 7W with IR cut filter ON) |
| Operating Temperature | -40°F ~ 140°F, Humidity ≤ 95% (non-condensing) |
| Physical | |
| Dimensions | 5.7" × 2.7" × 2.8" |
| Net Weight | 0.78 lbs |
| Weather Rating | IP67 Rated |
| Weight | 1.00 lbs |
|---|
