| PART NUMBER |
FKFE11PHU60-N |
| No. of Sources |
1 |
| Extension type |
Fiber |
| Link Port |
SFP* Data speed: 1.25 Gbps
Wave length: 1300nm
Fiber optical connector: LC Single mode Fiber |
| RECEIVER UNIT (RX) |
FKFE11PHU60R-N |
| Displays/Projectors ports |
1 x DP/HDMI |
| Max Output Resolution |
UHD 4K up to 3840×2160 @ 60 Hz
Up to 10 km*** |
| Mouse and Keyboard |
1 x USB 2.0 Type A, 2 x USB HID Type A |
| Audio OUT Jack |
1 x 3.5 mm Jack |
| IR Remote Port |
Mini PL (IN) |
| RS232 |
Terminal Block |
| TRANSMITTER UNIT (TX) |
FKFE11PHU60T-N |
| Displays Type |
1 x DP/HDMI |
| Mouse and Keyboard (TX) |
1 x USB 2.0 Type B, 1 x USB HID Type B |
| Audio IN Jack |
1 x 3.5 mm Jack |
| IR Remote Port (TX) |
Mini PL (OUT) |
| RCU |
Terminal Block |
| PoE / PoC |
No PoE / No PoC |
| Power Requirements |
Transmitter: 12V DC
Receiver: 12V DC |
| AC Input |
100 to 240 AC |
| Power Supply Type |
External |
| Dimensions |
140 (W) × 210 (D) × 28 (H) mm
5.5 (W) × 8.3 (D) × 1.1 (H) inch
(Transmitter & Receiver) |
| Weight |
1.1 kg (2.4 lbs) (Transmitter and Receiver) |
| Operating Temperature |
32°F to 104°F (0°C to 40°C) |
| Storage Temperature |
-4°F to 140°F (-20°C to 60°C) |
| Humidity |
0%-80% RH, non-condensing |
| Supported OS |
Windows, Linux, Mac |
| Product Certification |
CE, RCM, FCC class B, VCCI, TUV US, TUV Canada |
| Manufactured |
BAA & TAA Compliant |
| Product life-cycle |
10 years |
| Warranty |
2 Years |
