Description
The MIURA 8008I is a high-power, 8-channel Class D amplifier designed for fixed installations requiring flexibility, precision, and reliable high-output performance. Delivering up to 8×1000W at 4Ω, or 4×2000W at 100V in bridge mode, it supports both low-impedance (4/8/16Ω) and high-impedance (70/100V) lines with full asymmetric power distribution. Integrated Dante audio streaming (4 channels) and TCP/IP control (AES70 compatible) via EtherCON ports allow seamless integration into networked systems through INFINITO software. The amplifier also features AES3 digital inputs with link, to ensure compatibility with professional-grade systems. A front OLED display with encoder ensures onboard setup, while Euroblock I/O, GPIO, and comprehensive protection features guarantee safe, long-term operation in demanding installation environments.
Download Manual Features
- 8×1000W at 4Ω | 8×900W at 70V | 4×2000W BTL (100V or 8Ω)
- Class D topology with ultra-low distortion
- Full asymmetric loading with SE and BTL operation
- TCP/IP control (AES70) via INFINITO software
- 4-channel Dante audio receiver (24-bit, 48–96 kHz)
- AES3 digital audio input with link
- OLED display with push encoder for local setup
- Auto-Standby / Wake function
- Universal SMPS with Power Factor Correction
- Euroblock I/O and 8-channel GPIO
