Description
The SK21P-N is a 2-port DisplayPort KVM switcher designed to share a single keyboard, video, mouse and audio set between two computers. It provides a compact hardware solution that streamlines multi-computer workflows and reduces desktop clutter. The unit supports fast switching and common peripheral control functions to simplify daily operation.
Key features include DisplayPort 1.2 video support, USB keyboard and mouse interfaces, 3.5 mm audio and microphone jacks, and cross-system copy and paste functionality. The built-in clipboard transfer lets users move text and files between connected systems without a network connection. Local USB ports are standard type A for console peripherals and type B for host connections.
Video performance supports UHD 4K resolutions up to 3840×2160 at 30 Hz using DisplayPort 1.2 on both console and computer ports. Audio is handled via 3.5 mm stereo and microphone jacks for both console and host sides. Power is supplied externally at 12V DC, 1.5A and the unit is engineered to operate reliably within standard office temperature and humidity ranges.
Connectivity includes one DisplayPort 1.2 console output and two DisplayPort 1.2 computer inputs, USB Type A console ports for keyboard and mouse, and USB Type B computer-side connections. The unit is OS agnostic and supports Windows, Linux and Mac systems. Standard 3.5 mm jacks provide analog audio and microphone pass-through for each connected host.
This KVM switcher is suited to trading desks, IT administration stations, and multi-system control points where users must toggle control between two machines quickly and securely. It reduces the need for duplicate peripheral sets and saves desk space in compact or shared environments. Clipboard transfer and audio pass-through enhance productivity in mixed-platform scenarios.
Installation is straightforward using standard DisplayPort and USB cables and an external 12V power supply. The compact metal enclosure measures 177 x 82 x 35 mm and weighs approximately 0.52 kg, making it simple to position on a desk or install in shallow rack shelves. The unit is certified to common regulatory standards and backed by a two year warranty for business deployments.
