| Starting at 31,000 Lumens | 31000 lumens |
| Stunning clarity with WUXGA or true 4K-UHD | WUXGA / 4K-UHD |
| REC.709 color fidelity | REC.709 |
| Drop-in lens compatibility with original TITAN models | Yes |
| At just 125 lbs | 125 lbs |
| Starting at 31,000 Lumens | 31000 lumens |
| 4K-UHD & WUXGA Resolution | 4K-UHD / WUXGA |
| Up to 2000:1 Contrast | 2000:1 |
| New, compact design | Compact design |
| DisplayPort 1.2 | Supported |
| 2 x HDMI 2.0b HDCP 2.2 | 2 x HDMI 2.0b HDCP 2.2 |
| HDR processing | Supported |
| 2 x HDMI 1.4b HDCP 1.4 for Dual Pipe processing and Frame Sequential 3D Format | 2 x HDMI 1.4b HDCP 1.4 |
| Sequential Processing | 3D via single HDMI 1.4b |
| Dual Pipe Processing | 3D Left/Right via two HDMI1.4b |
| Syncronisation of active glasses | Active glasses sync |
| 3G-SDI with loop-through | 3G-SDI loop-through |
| DICOM simulation mode | DICOM simulation |
| DMX Art-Net | DMX Art-Net |
| Constant Brightness control | Constant Brightness |
| Multi-Projector Brightness control | Multi-projector control |
| Compatible with selected competitor lenses via lens converter | Lens converter compatible |
| Selectable EDID | Selectable EDID |
| Custom Start-up Logo | Custom logo |
| Geometry Correction | Geometry Correction |
| 4-Cornerstone Vertical & Horizontal Keystone Pincushion & Barrel Arc and Image Rotation | 4-Cornerstone / Keystone / Pincushion / Barrel / Arc / Rotation |
| Non-linear warp | Non-linear warp |
| Digital Zoom Pan and Scan | Digital Zoom / Pan / Scan |
| Blanking control for custom input window sizing | Blanking control |
| Scaling available for fixed aspect ratio screens | Scaling for fixed aspect ratio |
| Unscaled processing for pixel mapped display | Unscaled processing |
| Edge Blending | Edge Blending |
| Blending control available for all sides with width control | Blending control all sides |
| Correction for non-active pixels at the edge of the display | Edge pixel correction |
| Picture in Picture | PIP |
| Two sources can be displayed simultaneously using 2D inputs either picture in picture PIP or side by side PBP with the original aspect ratios maintained | PIP / PBP two 2D sources |
| HDBaseT Interface | HDBaseT |
| Built in support for reception of uncompressed High Definition Video over standard CAT5e/6 LAN cable | Uncompressed HD over CAT5e/6 |
| Allows projector to be placed up to 100m from source with low cost cabling | Up to 100m |
| Supports up to 4K UHD 3840 x 2160@60Hz 4:2:0 or 4K UHD 3840 x 2160@30Hz 4:2:2 | 3840x2160@60Hz 4:2:0 or @30Hz 4:2:2 |
| Four colour modes available | 4 modes |
| Powerful seven point colour correction for accurate colour matching with presets | 7-point colour correction |
| Easy colour temperature selection | Colour temperature selection |
| Manual seven point colour adjustment | Manual 7-point |
| Traditional lifts and gains | Lifts and gains |
| Projector Controller Software | Network control software |
| Intuitive user interface for network control | Intuitive UI |
| Simultaneous control of user-defined groups of projectors | Group control |
| At-a-glance monitoring of projector status | Status monitoring |
| Real-time clock provides daily on/off automation | Daily on/off automation |
| E-mail alerts for system status | E-mail alerts |
| 2D Graphics standards up to 4K-UHD 3840x2160 resolution at 60Hz via HDMI 2.0 HDBaseT DisplayPort inputs | 2D up to 3840x2160@60Hz |
| 3D Graphics standards up to dual-pipe WUXGA 120Hz via HDMI 1.4b inputs | 3D dual-pipe WUXGA 120Hz |
| 3G-SDI is SMPTE 292M SMPTE 259M-C and SMPTE 424M compliant | SMPTE 292M / 259M-C / 424M |
| 2D sources up to WUXGA 120Hz and 4K-UHD 60Hz can be displayed scaled to fit WUXGA | 2D scaled to WUXGA |
| 3D sources up to WUXGA 120Hz can be displayed scaled to fit WUXGA | 3D scaled to WUXGA |
| Sources greater than WUXGA will be displayed scaled to fit 4K-UHD | >WUXGA scaled to 4K-UHD |
| Sources up to WUXGA will be displayed scaled to fit WUXGA | <=WUXGA scaled to WUXGA |
| DisplayPort 1.2 | 1 |
| HDMI 1.4b | 2 |
| HDMI 2.0b | 2 |
| 3G-SDI in | 1 |
| 3G-SDI out | 1 |
| HDBaseT LAN | 1 |
| 3D Sync In | BNC 1 |
| 3D Sync Out | BNC 1 |
| LAN | RJ45 2 |
| RS-232 | 9-pin D-Sub 1 |
| Wired Remote | 3.5mm Stereo Jack 1 |
| 12V Trigger | 3.5mm Stereo Jack 2 |
| 3D Sync IR Out | BNC 1 |
| 3D Formats Supported | Sequential 1080p@100Hz, Sequential 1080p@120Hz, Sequential WUXGA@100Hz, Dual-Pipe 1080p@50Hz, Dual-Pipe 1080p@60Hz, Dual-Pipe WUXGA@50Hz, Dual-Pipe WUXGA@60Hz |
| HDTV Formats Supported | 1080p 24/25/30/50/60Hz, 1080i 50/60Hz, 720p 50/60Hz, 2K 24/25/30/50/60Hz, 4K-UHD 24/25/30/50/60Hz |
| Computer Compatibility Bandwidth | 498 Mpixels/sec via DisplayPort and HDMI2.0 |
| Remote Control | Addressable IR wireless wired onboard keypad |
| Automation Control | Crestron RoomView connected LAN RS-232 AMX DMX Art-Net |
| Served web pages | Status control network settings alert mail time error log OSD |
| Colour Temperature | 3200K to 9300K |
| Lamp Type Typical Lamp Life | Laser 20,000 hours |
| Lens Part No Focus Range Lens Shift | 105-607 0.67:1 fixed HB 1.1m-10m Vert 0.108U 0.108D Hor 0.044L 0.044R |
| Lens Part No | 105-608 1.12:1 fixed HB 3m-15m Vert 0.567U 0.45D Hor 0.188L 0.188R |
| Lens Part No | 109-236 1.16-1.49:1 zoom HB 3m-15m Vert 0.408U 0.408D Hor 0.188L 0.188R |
| Lens Part No | 105-610 1.39-1.87:1 zoom HB 4m-24m Vert 0.567U 0.45D Hor 0.188L 0.188R |
| Lens Part No | 105-611 1.87-2.56:1 zoom HB 4m-24m Vert 0.567U 0.45D Hor 0.188L 0.188R |
| Lens Part No | 105-612 2.56-4.16:1 zoom HB 9.1m-45m Vert 0.567U 0.45D Hor 0.188L 0.188R |
| Lens Part No | 105-613 4.16-6.96:1 zoom HB 12m-80m Vert 0.567U 0.45D Hor 0.188L 0.188R |
| Lens Part No | 109-235 6.92-10.36:1 zoom HB 12m-80m Vert 0.567U 0.45D Hor 0.188L 0.188R |
| Lens Mount | Motorised shift zoom focus |
| Intelligent Lens Memory | 10 user-definable presets |
| Mechanical Mounting Orientation | Front Rear table ceiling adjustable feet tabletop inverted pointing up down roll portrait |
| Power Requirements | 110VAC & 230VAC selectable 50/60Hz single phase |
| Power Consumption | 110V Typical TBD W Maximum TBD W 230V Typical 3400W Maximum TBD W |
| Thermal Dissipation | Max TBD BTU/Hour @110VAC Max 11600 BTU/Hour @230VAC |
| Fan Noise | Typ 50dBA High Altitude 52dBA Eco Typ 47dBA |
| Operating Temperature | 0C to 35C full power ECO up to 40C |
| Storage Temperature | -20C to 60C |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 10% to 90% non-condensing |
| Weight Chassis Only | 99 kg 218 lb |
| Dimensions | L 930mm W 650mm H 350mm |
