Description
ATEN VE814AR-ATA is an HDBaseT video receiver providing dual HDMI outputs and HDCP 2.2 compliance. It accepts HDMI over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable to extend video up to 100 m at 4K and supports a 10.2 Gbps data rate.
The unit passes RS-232 and dual-channel IR control signals to enable remote control of source and display devices and includes an Ethernet pass-through port for compatible devices. A Long Reach Mode permits 1080p extension up to 150 m over Cat 5e/6.
Built with a metal housing and ESD protection, the VE814AR-ATA uses ATEN EDID technology to maintain display EDID values when paired with a compatible transmitter. The receiver is rack-mountable and plug-and-play for straightforward installation.
Key Features:- Dual HDMI outputs: Two HDMI Type A outputs provide duplicate HDMI output to two displays
- 4K over HDBaseT: Supports 4K video up to 100 m (Cat 6a/ATEN 2L-2910 Cat6) at 10.2 Gbps
- Long Reach Mode: Extends 1080p up to 150 m over Cat 5e/6 for extended-distance deployments
- Control pass-through: RS-232 terminal block and dual IR channels allow remote device control
- EDID management: ATEN EDID Technology adopts display EDID for reliable output
- Protection and build: Metal housing with 8 kV/15 kV ESD protection for reliable operation
- Digital Signage: Distribute identical 4K or 1080p content to multiple displays in bars and retail
- Education / Lecture Halls: Central source distribution with RS-232/IR control for AV management
- Transit / Public Spaces: Remote displays for schedules and announcements using long-reach mode
