Description
The ATEN VE814AT-ATA is an HDBaseT HDMI Transmitter designed to extend an HDMI source to one local output and two remote displays over a single Cat 5e/6/6a or ATEN 2L-2910 Cat6 cable. As part of ATEN’s HDMI Extenders line, the VE814AT-ATA supports HDMI features including 3D and Deep Color while remaining HDCP 2.2 compliant.
The VE814AT-ATA delivers up to 4K video at distances up to 100 m (Cat 6a/ATEN 2L-2910 Cat6) and supports Long Reach Mode for 1080p to 150 m over a single Cat 5e/6 cable. The unit passes RS-232 and dual IR control signals for remote device management; note that this ATA variant does not provide Ethernet pass-through.
Engineered for digital signage and multi-display deployments, the VE814AT-ATA is rack-mountable, plug-and-play, and includes built-in 8 kV/15 kV ESD protection. Its dual remote outputs plus a local HDMI output make it practical for bars, classrooms, and transit hubs requiring identical content at multiple locations.
Key Features:- HDBaseT Video Extension: 4K up to 100 m over single Cat5e/6/6a or ATEN Cat6 for long-distance HDMI distribution
- Local plus Dual Remote Outputs: simultaneous local HDMI plus two remote displays to show identical content across three screens
- HDMI Compliance & HDCP: HDMI 3D Deep Color support and HDCP 2.2 compliance for protected 4K content
- Control Pass-Through: RS-232 and dual IR channels enable source and display control from remote and local ends
- Long Reach Mode: extends 1080p to 150 m over Cat5e/6 when enabled for greater distance legacy displays
- Protection & Mounting: built-in 8 kV/15 kV ESD protection and rack-mountable design for pro AV installations
- Digital Signage: replicate identical promotional or informational content across multiple displays
- Hospitality & Bars: deliver the same live feed to local and remote screens in lounges or sports bars
- Education: distribute instructional video across classrooms and lecture halls
- Transit Stations: show schedules and alerts on multiple displays across a facility
