| Video |
HDMI 2.0 with HDCP pass–through |
| Audio (Digital) |
Encoded audio formats and linear PCM up to 8 channels |
| Audio (Analog) |
Balanced Stereo (Output) |
| Serial (RS232) |
3–pin phoenix |
| USB |
Dual USB 2.0 (USB — A connectors) Note: Full USB 2.0 Support via Icron chipset |
| Ethernet |
10 Gb for Video/Audio/Control with 1 Gb Utility |
| Formats |
Supports all major VESA resolutions and variations including full HDMI 2.0 support: VGA: 640x480 (4:3), SXGA: 1280x1024 (5:4), 1080p/i: 1920x1080 (16:9), SVGA: 800x600 (4:3), WXGA: 1366x768 (16:9), QXGA: 2048x1536 (4:3), XGA: 1024x768 (4:3), SXGA+: 1440x1080 (4:3), Ultra HD: 3840x2160 (16:9), HDTV: 1280x720 (16:9), UXGA: 1600x1200 (4:3), 4K: 4096x2160 (17:9) |
| Custom resolutions |
Custom resolutions are supported at pixel clock rates up to 600 MHz |
| Video Other |
Color depth: 24 bit, 30 bit, 36 bit, 48 bit |
| Video Wall and Multiview |
Video Wall up to 15x15. Multiview with up to 19 sources |
| Signal transmission distance |
Cat6a: 100m |
| Copy Protection/Security |
HDCP 2.3, AES–128 Encryption, 802.1X compatible |
| Power input (locking connector) |
12V DC |
| Power |
Approximately 13 watts |
| Temperature |
Operating temperature: 32 F to 104 F <0 C to +40 C> Storage temperature: — 4 F to +176 F <–20 C to +80 C> |
| Humidity |
Operating/ Storage: 20% to 90% (Non–Condensing) |
| Accessories |
Z4KPWRCTR12: ZyPer 12V Power Center for use with up to 8 ZyPer Encoder/Decoders (all models). 1 RU. Includes rack ears, 8 3–foot locking 12V DC power cables, AC power cord. Z4KRACKXSE: ZyPer4K–XSE Rack Mount Kit. Holds up to 8 ZyPer4K–XSE Encoders/Decoders in standard 6RU space. Includes rack assembly and 8 carrier units. Z4KVESABRK: ZyPer4K VESA Bracket is a custom wall/desk/display mount bracket for ZyPer4K. Supports standard VESA parameters for mounting directly to rear of a display. 100x100, 100x200 and 200x200 VESA hole mounts are supported |
| Product Dimensions |
13.60cm x 13.70cm x 4.80cm (5.35" x 5.39" x 1.89" ) W, D, H |
| Product Weight |
1.0kg (2.2lbs) approx. |
| Shipping Dimensions |
17.70cm x 36.80cm x 8.80cm (6.97" x 14.49" x 3.46" ) W, D, H |
| Shipping Weight |
1.8kg (3.9lbs) approx. |
